Board Storage Racks

  • Category:Factory Equipment and Industrial SafetyStorage and Material Handling Equipment
INQUIRY

Board Storage - Special

板型收納 - 特殊

The O-KING Board Type automated storage and retrieval system is flexible and customizable to the customer’s needs. With up to 30 layers and 3 tons of load per layer, the whole system can store about 90 tons of board materials stacked with up to 30 types of board products, which can save up to 50% of storage space. With the optional weighing system, the human machine interface (HMI) can clearly indicate the quantity of board materials placed on each layer, and can also remotely check the storage status inside warehouses.

Space Saving

The vertical development of material storage can save more than 30% of space.

Management

High-density management of stored materials and quick inventory review.

Safety

High-density management of stored materials and quick inventory review.

Specification

Base size
3800*2300mm
weight
7000-16000 KG
Number of layers
15 / 20 / 25 / 30 L
Weight per layer
2000 / 2500 / 3000 KG
Color
Black and Red / Blue and White / Other

2.0 Ton

20L
25L
30L
Length
4422mm
4422mm
4422mm
width
4435mm
4435mm
4435mm
height
4884mm
5988mm
6868mm

2.5 Ton

20L
25L
30L
Length
4422mm
4422mm
4422mm
width
4435mm
4435mm
4435mm
height
5275mm
6225mm
7324mm

3.0 Ton

20L
25L
30L
Length
4422mm
4422mm
4422mm
width
4435mm
4435mm
4435mm
height
5626mm
6781mm
7837mm
